200 MES3000 Ethernet switch series
icmp_type
-
Type of ICMP messages used for ICMP packets filtration.
Possible message codes of the icmp_type field: echo-reply,
destination-unreachable, source-quench, redirect, alternate-
host-address, echo-request, router-advertisement, router-
solicitation, time-exceeded, parameter-problem, timestamp,
timestamp-reply, information-request, information-reply,
address-mask-request, address-mask-reply, traceroute,
datagram-conversion-error, mobile-host-redirect, mobile-
registration-request, mobile-registration-reply, domain_name-
request, domain_name-reply, skip, photuris or the number of
message type (0–255).
icmp_code
ICMP message code
Code of ICMP messages used for ICMP packets filtration.
Possible message codes of the icmp_code field: (0–255).
igmp_type
IGMP message type
Type of IGMP messages used for IGMP packets filtration.
Possible message codes of the igmp_type field: host-query,
host-report, dvmrp, pim, cisco-trace, host-report-v2, host-
leave-v2, host-report-v3 or the message type number (0–255).
destination_port
UDP/TCP destination port
Possible values of the TCP port field: bgp (179),
chargen (19), daytime (13), discard (9), domain (53), drip
(3949), echo (7), finger (79), ftp (21), ftp-data (20), gopher
(70), hostname (42), irc (194), klogin (543), kshell (544), lpd
(515), nntp (119), pop2 (109), pop3 (110), smtp (25), sunrpc
(1110, syslog (514), tacacs-ds (49), talk (517), telnet (23), time
(37), uucp (117), whois (43), www (80);
for UDP port biff (512), bootpc (68), bootps (67), discard (9),
dnsix (90), domain (53), echo (7 ), mobile-ip (434), nameserver
(42), netbios-dgm (138), netbios-ns (137), on500-isakmp
(4500), ntp (123), rip (520), snmp (161), snmptrap (162),
sunrpc (111), syslog (514), tacacs-ds (49), talk (517), tftp (69),
time (37), who (513), xdmcp (177).
Any number (0–65535).
source_port
UDP/TCP source port
list_of_flags
TCP flags
If a flag should be set for a filtration rule, "+" is specified
before the flag; otherwise "-" is specified. Possible flags: +urg,
+ack, +psh, +rst, +syn, +fin, -urg, -ack, -psh, -rst, -syn, and -fin.
If several flags are used for the same filtration rule, they are
written in one line without spaces. For example: +fin-ack.
disable_port
Disables a port
Disables the port which was used to send a packet fulfilling the
requirements of a deny command which describes the field.
log_input
Message log
Enables message log registration when a packet is received
which corresponds to the record.
offset-list
Name of user templates list
Specifies that the user templates list should be used for
packets recognition. Every ACL may have its own templates list
defined.
index
Rule index
The index indicates position of the rule in a list and its priority.
The lower the index, the higher the priority. The possible
values are 1–2,147,483,647.
In order to select the whole range of parameters except dscp and ip-precedence, the any
parameter is used.
As soon as at least one record has been added to ACL, the last record is set by default to
deny any any any that means that all packets which do not fulfil ACL requirements will be
dropped.
Table 5.247 Configuration commands for IP-based ACLs
Command
Action
permit protocol
{any|source source_wildcard}
{any|destination destination_wildcard}
[dscp dscp | precedence precedence]
[time-range time_name] [index index]
[offset-list offset_list_name]
Adds a permit filtration record for a protocol. Packets which fulfil the
record's requirements will be processed by the switch.
