(0x66 0x64 0x74 = 'tdf' backwards, !)
133-139
0x01 0x7C 0x03 0x64 0x63
0x6C 0xnn
0xnn = LCD-contrast, offset from standard settings,
8-bits value with sign. Allowed area is -10
(brightest) to +10 (darkest).
(0x64 0x63 0x6C = 'lcd' backwards)
140-146
0x01 0x7C 0x03 0x6E 0x61
0x6C 0xnn
0xnn = Code for language on the LCD menu.:
0x00 = English
0x01 = Swedish
0x02 = German
(0x6E 0x61 0x6C = 'lan' backwards)
147-153
0x01 0x7C 0x03 0x65 0x6C
0x73 0xnn
0xnn = Time from latest tangent activity until
CMeX50 goes to sleep mode.
Allowed values are 0x00..0xFF (0..255) minutes.
(0x65 0x6C 0x73 = 'sle' backwards, sleep)
154-158
0x0A 0xFD 0x16 0xnn 0xnn
0xnnnn = Password for login to LCD-menu, four
digits, packed BCD.
159-165
0x04 0xFD 0x0B 0xnn 0xnn
0xnn 0xnn
0xnnnnnnnn = Tag for user configuration, 32-bits
binary.
This value can be written to the CMeX50 to
indicate a specific configuration ID. The value is
reset when changes are made in the LCD menu.
166-173
0x02 0x7C 0x03 0x61 0x66
0x77 0xnn 0xnn
0xnnnn = Fine-tuning of the radio frequency, in
steps of 38,147Hz. 16-bits value with sign.
Example:
0x0000 = No adjustment
0x0069 = +105 that gives +105*38,147Hz = +4kHz
0xFF07 = -249 that gives -249*38,147Hz = -9,5kHz
(0x61 0x66 0x77 = 'wfa' backwards, wireless
frequency adjustment)
174-180
0x01 0x7C 0x03 0x66 0x69
0x61 0xnn
0xnn = FIFO-mode for automatic installation:
0x00 = FIFO-mode off. Installation of new meters
stops when the meter list is full (800 meters).
0x01 = FIFO-mode is on. If CMeX50 is in continuous
installation mode and a telegram from a new
meter is received when the meter list is full, the
meter with the oldest telegram will be deleted, and
the new meter will be installed.
(0x66 0x69 0x61 = 'aif' backwards, autoinstall fifo)
181-190
0x04 0x7C 0x03 0x63 0x72
0x72 0xnn 0xnn 0xnn 0xnn
0xnnnnnnnn = Number of times the radio has been
rebooted, due to no accurate telegram has been
received the last 30 minutes. 32-bits binary value
(0x63 0x72 0x72 = 'rrc' backwards, radio restart
counter)
191-197
0x01 0x7C 0x03 0x61 0x74
0x73 0xnn
0xnn = Setup for STATUS-byte in telegram from
virtualized meters:
