Embedded Systems LM5p-GSMC User Manual

8
Device specification
Types of product
LogicMachine5 Reactor GSM Power CANx LM5p-GMSC
LogicMachine5 Reactor GSM Power KNX LM5p-GMS
Standards and norms compliance
EMC: EN61000-6-1
EN61000-6-3
PCT Certificate
Technical data:
Power supply: 2 x 24V DC on terminal connectors (1 for LM powering, 1
for
external relay powering) or
24V DC Passive Power-over-Ethernet
Power consummation: 1.3W
Interface: GSM module with
Antenna 1
Push-push micro-SIM
connector 1
10BaseT/100BaseTX 1
RS-485 1
RS-485/RS-232 1
(switchable in software 
full-duplex=RS232,
half-duplex=RS485)
USB2.0 1
Analog input/Digital output 16
Analog input 0-10V 1
Analog inputs for current
Measurement clamps 3 (sensor specification)
1-Wire 1
CAN FT 1 (protocol features)
GSM modem
GSM module type Quectel UG95
Frequencies 900/2100MHz @UMTS
900/1800MHz @GSM
Worldwide UMTS/HSPA and GSM/GPRS/EDGE coverage
