9 Technical Data
Trigger Mode automatic
manual
external
Coupling Device
3
Direct Output
Internal CDN
3
The direct output must not be connected to powered pins. When a test on powered pins is necessary, proper coupling
elements, e.g. 0.5 uF coupling capacitors, need to be used. Alternatively CDN outputs can be used since those are fit
with coupling capacitors.
