EMC VNX Series Installation Guide

3. Cross-connect blade enclosure 0 MMA port 0 to blade enclosure 1 MMA port 1 on the
A side. See cable 3.
4. Cross-connect blade enclosure 0 MMB port 0 to blade enclosure 1 MMB port 1 on the
B side. See cable 4.
Figure 39 Cabling SPs to two blade enclosures
2
AC
!
2
1
1
0
0
0
11
0
1
2
3
4
Cable your system
Cabling for two blade enclosures 51

EMC VNX Series Specifications

General

Management Interface	Unisphere
Drive Support	SAS, NL-SAS, Flash (SSD)
RAID Levels	RAID 0, 1, 3, 5, 6
Protocols Supported	Fibre Channel, iSCSI, NFS, CIFS
Data Services	Deduplication, Compression, Snapshots, Replication
Processor	Intel Xeon
Operating System	VNX Operating Environment (block), VNX File Operating Environment (file)
