Figure 47 3U,15 3.5" drive DAE
A
B
#
X4
6Gb SAS
#
X4
6Gb SAS
VNX-000266
SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS
Assembling DAEs
CAUTION
The DAE is heavy and should be installed into a rack by two people. To avoid personal
injury and/or damage to the equipment, do not attempt to lift and install the enclosure
into a rack without a mechanical lift or help from another person.
Unpacking DAEs
Procedure
1. Unpack the shipping containers.
2. Verify the contents.
For damaged or missing components, notify your Sales associate immediately for
replacements.
Add additional storage
Assembling DAEs 63
