EMC VNX Series Installation Guide

92 pages

To Next Page

To Previous Page

Table 3 2U, 25 2.5" drive DAE

2U, 25 2.5" drive DAE

(1)

6 Gb

SAS

6 Gb

SAS

Mounting screws (4)

Adjustable rail kit

Rails (2)

Screws (3 per rail)

Power cables (2)

Note

Illustrations show standard US power cables.

SAS cables (2)

mini-SAS to mini-

SAS connectors

Bezel (1)

Add additional storage

64 EMC VNX Series VNX5600 Unified Installation Guide
