28
EMC VNX5500 File Installation Guide
3. Connect CS0 to the customer modem, if applicable as shown in Figure 15.
4. Connect your public LAN via a CAT5e or better Ethernet cable (customer supplied) to the CS0
MGMT extension cable as shown in Figure 15.
Figure 15 Cabling CS0 to modem and public LAN
Serial
console
MGMT
CS
B
MODEM socket
VGA plug
A
IPMI port
B
MGMT
Modem
PDU B
Control Station 0
Rear
CS0 B
CS0 MGMT
B
C
To cable to
Blade Encl 0 MMB Port 1
Cable to
public LAN
E
A
VNX-000201
