A-15
Reference Data
CENELEC Intrinsic Safety and Dust Certification
CENELEC Type N Certification
CENELEC Flameproof Certification
Special Conditions
When installed particular precautions must be taken to ensure
taking account with the effect of the fluid temperature, that the
ambient temperature of the electrical parts of the apparatus is
comprised between -50 °Cand70°C.
I1 ATEX Marking Ex II 1 GD T 70°C
Certification No. BAS99ATEX1222
EEx ia IIC T5 (T
amb
= -50 to 40 °C)
EEx ia IIC T4 (T
amb
= -50 to 70 °C)
Entity Parameters:
U
i
= 30 V
I
i
(1)
= 300 mA
P
i
(1)
= 1 W
C
i
= 0.0 m F
L
i
= 40 m H
(1) Total for transmitter
N1 ATEX Marking Ex II 3 GD T70°C
Certification No. BAS99ATEX3221
EEx nL IIC T5 (T
amb
= -40 °C to 70 °C)
42 Vdc max
ED ATEX Marking Remote Mount:
Ex II 2 (1) G T70°C
ATEX Marking Integral Mount
Ex II 1/2 G T70°C
KEMA Certification No. 99ATEX3852X
EEx d [ia] IIC T6
(T
amb
= -50 °C to 70 °C)
Standards Association of Australia (SAA)
(1)
Certifications
(1) Pending final approval
E7 Flameproof:
Ex d [ia] IIC T6 (T
amb
= 40 °C)
Ex d [ia] IIC T4 (T
amb
= 70 °C)
Class I, Zone 1; IP66
I7 When connected in accordance with Rosemount Drawing
08800-0121
Intrinsic Safety:
Ex ia IIC T6 (T
amb
= 40 °C)
Ex ia IIC T4 (T
amb
= 70 °C)
Class I, Zone 0
Entity Parameters:
U
i
= 30 V
I
i
(2)
= 300 mA
P
i
(2)
= 1 W
C
i
= 0.016 mF
L
i
= 40 mH
(2) Total for transmitter
N7 Type N: Ex n IIC T6 (T
amb
= 40 °C)
Ex n IIC T4 (T
amb
= 85 °C)
Class I, Zone 2
