Section 7: Parameter Menu
Parameter Menu
CAUTION: NOTE TRAVEL LIMITS
When installing the actuator on an gear or a thrust unit, please take into account the limits
and factors of the gear / thrust unit at parametrization.
CAUTION: SET LIMITS CORRECTLY
When using end limit switch off by torque, the end position limit must be set before
reaching the torque limit. Accordingly, the actuator will only signal the nal end position
if the congured torque and the associated end position are reached. If the end position is
not reached, a torque error is reported (see Section 6.2.2)
7.2 Parameter Group: Torque
If no torque was specied with the order, the actuator is supplied from the factory with the
maximum congurable torque.
Table 5. Torque Parameter Group
Menu Item
Sub Menu
Item
Poss.
Setting
Notes / Comments
P2.1 Torque Open 8 - 32Nm
2)
switch off torque in OPEN direction CAUTION: The range
can be restricted via the menu item P2.3
P2.2
Torque Close 8 - 32Nm
2)
As P2.1 but in CLOSED direction
P2.3 Torque Torque limit 8 - 32Nm
2)
Torque to protect the valve, the transmission or the
thrust unit.
This value limits the setting of the Parameters P2.1 and P2.2
and to prevent an erroneous increase above the allowed
value of these two parameters.
P2.4 Torque Latching {Off (0)} Unassigned in RTS Compact Linear CL series
P2.7 Torque Hysteresis {0: 50%} Unassigned in RTS Compact Linear CL series
2)
representative for CL03
CAUTION: NOTE GEAR AND THRUST UNITS
When installing the actuator on an additional gear, please take into account the
corresponding values of the gear / thrust unit as you enter the actuator parameters.
To achieve an effective output torque (incl. gear) / output power (including thrust unit)
ratio, the factor gear/thrust unit must be considered.
