Emerson Bettis RTS CL Series User Manual

User Instructions
MAN-02-04-60-0350-EN Rev. 3 February 2019
80
Section 16: Technical Data and Certifications
Technical Data and Certications
16.3 Analogue Inputs
Table 34. Input 1: Setpoint Value
Characteristic Value
Current range: 0-25mA
Resolution: 14Bit
Accuracy: 0,5%
Input resistance: 60 Ohm
Analog input 1 is electrically isolated from the rest of the electronic system.
Table 35. Input 2: External Actual Value
Only in Conjunction with the PID Controller
Characteristic Value
Current range: 0-20,8mA
Resolution: 12Bit
Accuracy: 0,5%
Input resistance: 120 Ohm
Jumper JP6 can be used to switch analog input 2 from a passive input (default) to an input
with internal 24 V power supply (for 4. . . 20 mA, two-wire transmitters).
NOTE:
The analog input 2 is referenced to common of the electronic system and the auxiliary
power supply.
16.4 Analogue Output
Table 36. Analog Output
Characteristic Value
Current range: 0-20,8mA
Resolution: 12Bit
Accuracy: 0,5%
Input resistance: 600 Ohm
