February 2019
User Instructions
MAN-02-04-60-0350-EN Rev. 3
79
Section 16: Technical Data and Certifications
Technical Data and Certications
Figure 73 5 inputs with common = "-" using internal 24V (e.g. for dry contacts)
Figure 74 3 separated inputs using 3 separated external 24V
Figure 75 3 separated inputs using 3 separated external 24V
