Section 7: Parameter Menu
Parameter Menu
Section 7: Parameter Menu
For each parameter group, you can nd a description tabular overview of the menu items
and possible congurations. The parameter list below also includes all possible options
per menu item. Please note that some of the menu items listed and described may not be
delivered with your conguration.
7.1 Parameter Group: End Limit
These parameters are used to congure the end position and switch off behavior of the
actuator. In this regards, it is important to ensure that the basic mechanical conguration
described in Section 5.4 has already been made.
CAUTION: SET CORRECT PARAMETERS
Ensure that these parameters are set during commissioning before operating the actuator.
In addition, the settings in the "Torque" menu (see Section 7.2) must be compared with the
permissible values of the valve and corrected as appropriate)
CAUTION: NOTE OPEN/CLOSE VALUES
Generally, 100% stands for fully open and 0% for fully closed. Please note that these values
cannot be changed.
