Emerson Bettis RTS CL Series User Manual

February 2019
User Instructions
MAN-02-04-60-0350-EN Rev. 3
83
Section 16: Technical Data and Certifications
Technical Data and Certications
16.6 Connections
16.6.1 Connections for non explosion-proof version
Table 38. Non-explosionproof Connections
Connection Value
Power/motor:
Industrial plug with 6 pins Screw connection
16A, max. 2,5mm2 , AWG14
Control signals
Industrial plug with 24 pins
Screw connection
16A, max. 2,5mm2 , AWG14
Optionally, contacts are available in crimp or cage clamp designs.
16.6.2 Connections for explosion-proof version
Table 39. Explosion-proof Connections
Connection Value
Power/motor:
terminals with screw connection
16A, 0,5. . . 4mm2 , AWG20. . . AWG12
Control signals
terminals with screw connection
4A, 0,5. . . 2,5mm2 , AWG20. . . AWG14
16.7 Miscellaneous
Table 40. Miscellaneous
Characteristic Value
Ambient temperature
non explosion-proof version -25 . . . +60°C
explosion-proof version -20 . . . +40°C (according EN 60079-0)
ex version with extended temperature range -40 . . . +60°C
Protection according to EN 60529: IP67
Standard colour: RAL7024
