User Instructions
MAN-02-04-60-0350-EN Rev. 3 February 2019
46
Section 7: Parameter Menu
Parameter Menu
7.9 Parameter Group: Binary Outputs
The controller is equipped with 8 freely congurable binary outputs. Please nd further
information on technical data of the binary outputs in Section 16.1. Provided with external
supply, binary outputs are optically isolated from the rest of the controller.
Default binary outputs are as follows:
• Output 1: Ready
• Output 2: End position OPEN
• Output 3: End position CLOSED
• Output 4: Run OPEN
• Output 5: Run CLOSED
• Output 6: Torque
• Output 7: LOCAL
• Output 8: REMOTE
Table 13. Binary Outputs Parameter Group (1)
Menu
Item
Sub Menu
Item
Poss. Setting Notes / Comments
P10.1
Binary
Output
Output 1
0: User dened Optional
1: Ready Actuator is ready
2: Fault General fault; actuator is not ready
3: Open Actuator is in open position
4: Closed Actuator is in closed position
5: Running Open Actuators runs in direction Open
6: Running
Closed
Actuators runs in direction Closed
7: Runing Actuator is running in either Open or Closed
8: Torque Open
Switch off torque was reached in Open direction-
actuator has been switched off
9: Torque Closed
Switch off torque was reached in Closed direction-
actuator has been switched off
10: Torque
Switch off torque was reached in either Closed or Open
direction
11: Travel Open The Open end postion has been reached
12: Travel Closed The Closed end postiion has been reached
13: Pos. > Int.1 Position > Intermediate position 1
14: Pos. < Int.1 Position < Intermediate position 1
15: Pos. > Int.2 Position > Intermediate position 2
16: Pos. < Int.2 Position < Intermediate position 2
17: Pos. > Int.3 Position > Intermediate position 3
18: Pos. < Int.3 Position < Intermediate position 3
19: Pos. > Int.4 Position > Intermediate position 4
20: Pos. < Int.4 Position < Intermediate position 4
21: Local Local oerating mode (selector switch in position)
To Next Page
