Section 7: Parameter Menu
Parameter Menu
Table 14. Binary Outputs Parameter Group (2)
Menu
Item
Sub Menu
Item
Poss. Setting Notes / Comments
P10.1
Binary
Output
Output 1
22: Remote
Remote operating mode (selector switch in position
Remote)
23: Off Off operating mode (selector switch in the Off position)
24: No function No function
25: Motor error The motor temperature sensor has reported an error
26: Always Signal is always on
27: Never Signal is always off
28: Binary Input 1 Forwarding of binary input to output
29: Binary Input 2 Forwarding of binary input to output
30: Binary Input 3 Forwarding of binary input to output
31: Binary Input 4 Forwarding of binary input to output
32: Binary Input 5 Forwarding of binary input to output
33: Torque Open ma.
As Torque OPEN although it will supress (mask) this
signal in the end position upon torque-dependent
switch off.
34: Torque Closed ma.
As Torque CLOSED although it will supress (mask) this
signal in the end position upon torque-dependent
switch off.
35: Ready Remote Ready and Remote operating mode
36: Ready Local Ready and Local operating mode
37: Ready
Local/remote
Ready and Local or Remote mode
38: Lock Open
Lock OPEN is enabled. OPEN command is internally
queued with the highest priority and will not be
dropped even in the end position
39: Lock Closed
Lock CLOSED is enabled. CLOSED command is internally
queued with the highest priority and will not be
dropped even in the end position
40: Failsafe OK1 Failsafe OK (only for failsafe actuators)
41: Failsafe OK2 Failsafe OK and Ready (only for failsafe actuators)
42: Failsafe OK3
Failsafe OK,Ready and Remote
(only for failsafe actuators)
43: Lock Lock Open or Lock Closed is enabled.
44: Ready/Torque OK Actuator is ready and no torque switch off
45: Ready/Remote/
Torque OK
Actuator is ready for operation in REMOTE mode and no
torque switch off
46: Pos.=Int1
Position = Intermediate position 1. The width of the
interval is set with the parameter P8.6
