Emerson Bettis RTS CL Series User Manual

February 2019
User Instructions
MAN-02-04-60-0350-EN Rev. 3
45
Section 7: Parameter Menu
Parameter Menu
Table 12. Binary Inputs Parameter Group (2)
Menu
Item
Sub Menu
Item
Poss. Setting Notes / Comments
P9.1
Binary
Input
Input 1
24: Lock Closed
Trigger lock CLOSED (in LOCAL and REMOTE mode).
Actuator moves with the highest priority to CLOSED;
command continues internally active after reaching the
end position CLOSED. Dropping only with LOCK OFF,
Supply OFF or operating mode OFF.
25: Lock Off Drop the lock
26: Failsafe
Trigger the failsafe function in all operating modes (only
functional in failsafe actuators).
27: Failsafe inv. As Failsafe but active low
28: Lock Open inv. As Lock Open but active low
29: Lock Closed
inv.
As Lock Closed but active low
30: Lock Off inv. As Lock Off but active low
31: Intermediate
position1
Approach intermediate position 1 (P8.1) in REMOTE
mode (x position approach). There is no repositioning
upon reaching the intermediate position within the
hysteresis (see P8.6) Higher priority than intermediate
position 2, 3 and 4
32: Intermediate
position2
As intermediate position 1 but with higher priority than
intermediate positions 3 and 4
33: Intermediate
position3
As intermediate position 1 but with higher priority than
intermediate position 4
34: Intermediate
position4
As intermediate position 1 but with lowest priority
35: Emergency
position
Approach emergency position (P 8.5). As intermediate
position 1 but with higher priority than intermediate
positions 1, 2
36: Intermediate
position1 inv.
As Intermediate position 1 but active low
37: Intermediate
position2 inv.
As Intermediate position 2 but active low
38: Intermediate
position3 inv.
As Intermediate position 3 but active low
39: Intermediate
position4 inv.
As Intermediate position 4 but active low
40: Emergency
position inv.
As Emergency position but active low
41: Travel Open
42: Travel Close
43: Travel Open inv.
44: Travel Close inv.
45: Failsafe lock
46: Failsafe lock inv.
P9.2 Input 2 see Input 1 ---
P9.3 Input 3 see Input 1 ---
P9.4 Input 4 see Input 1 ---
P9.5 Input 5 see Input 1 ---
