Section 7: Parameter Menu
Parameter Menu
Table 11. Binary Inputs Parameter Group (1)
Menu
Item
Sub Menu
Item
Poss. Setting Notes / Comments
P9.1
Binary
Input
Input 1
0:no function This input has no function
1: Open
OPEN command in REMOTE mode (selector switch in
position REMOTE).
2: Closed
CLOSED command in REMOTE mode (selector switch in
position REMOTE).
3: Stop
STOP command in REMOTE mode (selector switch in
position REMOTE).
4: Open Self-hold
Self-hold for OPEN, i.e., a short pulse is sufcient and the
actuator moves then into the end position. Use the STOP
command to stop the actuator.
5: Closed Self hold Self-hold for CLOSED, see OPEN SELF-HOLD
6: Emergency
Open
Superimposed run command; run the actuator in direction
OPEN regardless of whether the selection switch is set to
REMOTE or LOCAL operation
7: Emergency
Closed
Superimposed run command; run the actuator in direction
CLOSED regardless of whether the selection switch is set to
REMOTE or LOCAL
8: Release
The actuator may be operated only with a switched signal.
Both in local and remote operation
9: Open/Closed
The actuator moves towards OPEN if input is active and
towards CLOSED otherwise
10: Close/Open
The actuator moves towards CLOSED if input is active and
towards OPEN otherwise
11: Positioner Release of the postioner
12: Open inv. As open but active low
13: Close inv. As CLOSED but active low
14: Stop inv. As STOP but active low
15: Open
Self-Hold inv.
As Open Self-Hold but active low
16: Closed
Self-Hold inv.
As Closed Self-Hold but active low
17: Emergency-
Open inv.
As Emergency-Open but active low
18: Emergency-
Closed inv.
As Emergency-Closed but active low
19: Block
With activated (switched) signal, the actuator is locked for
operation also in local mode
20: Contoller lock Positioner lock
21: Release Local The actuator may be operated only with a switched signal.
22: Block Local As Release Local but active low
23: Lock Open
Trigger lock OPEN (in LOCAL and REMOTE mode).
Actuator moves with the highest priority to OPEN;
command continues internally active after reaching the
end position OPEN. Dropping only with LOCK OFF, Supply
OFF or operating mode OFF.
