February 2019
User Instructions
MAN-02-04-60-0350-EN Rev. 3
77
Section 16: Technical Data and Certifications
Technical Data and Certications
Jumpers JP1 . . . JP3 can be used to interconnect the binary inputs to groups with
separate earths:
Figure 67 5 Inputs with Same Common
Figure 68 2 Separated Groups of 2 Inputs with Same Ground
Input IN3 is Disabled.
Figure 69 3 Separated Inputs; Inputs IN2 and IN4 are Disabled.
