Page #38 background imageLoading...
Page #38 background image
28 100-412-182 REV. 06
Password
A user-defined access code for the secure areas of the
Power Supply user’s controls.
Password Protection
Enables lock-out of the Power Supply’s weld parameter
modification by using a user-defined password.
Peak Power Cutoff
A power value that terminates the ultrasonics when peak
power is not the primary control mode.
Pk Pwr Mode
Peak Power Mode. A mode of operation in which
ultrasonics are terminated at a user-specified power
value in percentage of maximum.
Plus Limit
The user-defined upper limit. See Control Limits,
Suspect, Reject and Missing Part Limits in the Power
Supply manual.
Post Weld Seek
Used to determine the operating frequency of the Stack,
after the Hold and/or Afterburst portion of the weld cycle.
Ultrasonics are run at a low level (5%) amplitude during
this step, and the frequency is stored to memory.
Power Graph
A printed graph of power in percentage maximum plotted
against time.
Preset
A method of saving the power supply’s user-set
parameters to memory, for a given Setup. The Power
Supply model may allow multiple presets for easy recall
of a Setup’s parameters, for a given part, process or
operation. Presets can be labeled by the user or the
system.
Preset Name The ability to name a preset in customer-defined terms.
Pretrigger
The setting that causes ultrasonics to start before contact
with the part (or, before the set Trigger Force has been
met).
Pretrig Amp
Pretrigger amplitude. The amplitude at the converter
during pretrigger.
Print on Alarm
Allows the user to set up printing automatically when an
alarm occurs.
Print on Sample
Allows the user to set up printing automatically based on
the number of cycles performed.
Ready Position
State in which the welder is retracted to the home
position and ready to receive the start signal, ready to
operate.
Recall Preset
Allows the user to activate a preset from memory for
purposes of operation or modification.
Reject Limits
User-definable limits at which the violating cycle is
identified as having produced a bad part.
Table 2.2 Glossary of Terms
