Emerson Branson 2000X User Manual

100-412-182 REV. 06 29
Required
State used with limits indicating that a reset will be
required when the limit is exceeded. The reset is
accomplished by using the reset key on the front of the
Power Supply.
Reset Required
State used with limits indicating that a reset will be
required when the limit is exceeded. The reset is
accomplished by using the reset key on the front of the
Power Supply, or by external reset at the User I/O.
Run Screen
The screen showing weld status, alarms, weld count, and
process information.
Save Preset Stores a programmed set of weld parameters as a Preset.
Scrub Time
In Ground Detect mode, the amount of time after
detection of a ground condition to the termination of
ultrasonics.
Seek
The activation of ultrasonics at a low-level (5%)
amplitude, for the purpose of finding the resonant
frequency of the Stack.
Serial Port
A RS232 port provided to you for external data
communications.
Step @ Col
User-definable collapse distance at which AmpA is
changed to AmpB.
Step @ Energy User-definable point at which AmpA is changed to AmpB.
Step @ Ext Sig
Allows you to shift either force or amplitude based upon
an external signal.
Step @ Power User-definable point at which AmpA is changed to AmpB.
Step @ Time User-definable point at which AmpA is changed to AmpB.
Suspect Limits
User-definable limits used to identify a part as being
potentially bad (suspect).
Test Scale
The magnification of the power bar on the front panel of
the Power Supply, useful for lower-power applications
that want a more accurate (but smaller scale).
Time Mode Terminates the ultrasonics at a user-specified time.
Timeout
A time at which the ultrasonic energy terminates if the
main control parameter has not been reached.
Trigger Beeper
An audible signal sounded when the trigger force has
been met.
Trig Delay
Trigger Delay. A user-programmable time delay between
engagement of the trigger and start of ultrasonics and
ramping of force to the weld force.
Table 2.2 Glossary of Terms
Name Description
