30 100-412-182 REV. 06
User-defined Limits
For process resultants, where - is the user-defined lower
limit, and + is the user-defined upper limit:
• ± S/R Energy: The energy reached during the weld
• ± S/R Freq: The peak frequency reached during a weld
• ± S/R Power: The peak power as a percentage of the
maximum reached during the weld
• ± S/R Abs D: The Absolute distance reached during the weld
from the Upper Limit Switch
• ± S/R Col D: The collapse distance reached from trigger to
end of weld
• ± S/R Trg D: The distance at which the trigger occurred
• ± S/R Time: The weld time reached during the weld
Weld Count Count of acceptable weld cycles.
Weld Energy
The energy specified to be applied to the part during the
weld cycle.
Weld History The last 50 weld summary data lines are saved.
Weld Scale The power bar LED scale during weld.
Weld Results
A one-line summary of information concerning the last
weld cycle.
Weld Time The time for which ultrasonics are on.
Table 2.2 Glossary of Terms
Name Description
To Next Page
