If the cabinets are to be bolted together,
the side panels and hangers must be
removed before beginning.
Note: Battery cabinets for 625-1100kVA
UPS models can be bolted to the right of
the UPS. However, the cabling must be
routed externally.
Note: For 625kVA installations, the battery cabinets can
mount to left of UPS and cabling be routed internally.
For 1100kVA installations, the battery cabinets can be
bolted to the module on either side, but the power cables
must be routed externally to the DC input section.
If the cabinets are to be bolted together,
the side panels and hangers must be
removed before beginning.
Note: If a maintenance bypass cabinet is
used, it must be installed on the right side
of the Liebert NXL UPS
To Next Page
