Emerson Liebert NXL User Manual

Specifications
69
Table 16 Recommended conduit and cable sizes
Rectifier Input
UPS Rating
Voltage, VAC Nominal Selection (#) Conduit Size, Ph, GkVA kW
625 625 480 (3) 3.5C 3-600kcmil, #4/0AWG
625 625 575 (3) 3C 3-500kcmil, #2/0AWG
625 625 600 (3) 3C 3-500kcmil, #2/0AWG
1100 1100 480 (5) 3.5C 3-600kcmil, 250kcmil
1100 1100 575 (4) 3.5C 3-600kcmil, #4/0AWG
1100 1100 600 (4) 3.5C 3-600kcmil, #4/0AWG
Bypass Input
UPS Rating
Voltage, VAC Nominal Selection (#) Conduit Size, Ph, G kVA kW
625 625 480 (4) 3.5C 3-500kcmil, 2-250kcmil, #2/0AWG
625 625 575 (3) 3C 3-350kcmil, 2-#4/0AWG, #1/0AWG
625 625 600 (3) 3C 3-350kcmil, 2-#4/0AWG, #1/0AWG
1100 1100 480 (5) 4C 3-600kcmil, 2-350kcmil, #4/0AWG
1100 1100 575 (5) 4C 3-600kcmil, 2-350kcmil, #4/0AWG
1100 1100 600 (5) 4C 3-600kcmil, 2-350kcmil, #4/0AWG
Output
UPS Rating
Voltage, VAC Nominal Selection (#) Conduit Size, Ph, G kVA kW
625 625 480 (4) 3.5C 3-500kcmil, 2-250kcmil, #2/0AWG
625 625 575
(3) 3C 3-350kcmil, 2-#4/0AWG, #1/0AWG
625 625 600
(3) 3C 3-350kcmil, 2-#4/0AWG, #1/0AWG
1100 1100 480 (5) 4C 3-600kcmil, 2-350kcmil, #4/0AWG
1100 1100 575 (5) 4C 3-600kcmil, 2-350kcmil, #4/0AWG
1100 1100 600 (5) 4C 3-600kcmil, 2-350kcmil, #4/0AWG
Battery
UPS Rating
Voltage, VAC Nominal Selection (#) Conduit Size, Ph, G kVA kW
625 625 480 (5) 3C 2-600kcmil, 250kcmil
625 625 575
(5) 3C 2-600kcmil, 250kcmil
625 625 600
(5) 3C 2-600kcmil, 250kcmil
1100 1100 480 (7) 3.5C 2-750kcmil, 500kcmil
1100 1100
575
(7) 3.5C 2-750kcmil, 500kcmil
1100 1100
600
(7) 3.5C 2-750kcmil, 500kcmil

Emerson Liebert NXL Specifications

General

Brand	Emerson
Model	Liebert NXL
Category	UPS
Language	English
