Specifications
65
Notes on Tables
1. Nominal input current (considered continuous) is based on full-rated output load. Maximum
current includes nominal input current and maximum battery recharge current (considered
noncontinuous). Continuous and noncontinuous current are defined in NEC 100.
2. Maximum input current is controlled by the current limit setting, which is adjustable. Values
shown are for maximum current limit. If a smaller input feed breaker is used, the input current
limit can be adjusted; see your Emerson representative for more information.
3. The Rectifier Input Feed Breaker must be set to withstand the Liebert NXL transformer inrush of
up to eight times the nominal current.
4. All recommended external overcurrent protections are based on 100% rated breakers.
5. For breaker coordination while the module is overloaded, see the current versus time values on
the overload curves.
6. Nominal battery voltage is shown at 2.0 volts/cell.
Table 12 Current ratings—rectifier input
UPS Rating
Voltage
VAC
Nominal
Current
Maximum
CurrentkVA kW
625 625 480 903 954
625 625 575 757 795
625 625 600 725 762
1100 1100 480 1534 1605
1100 1100 575 1342 1379
1100 1100 600 1286 1322
Table 13 Current ratings—bypass input
UPS Rating
Voltage, VAC
Nominal
CurrentkVA kW
625 625 480 752
625 625 575 628
625 625 600 601
1100 1100 480 1323
1100 1100 575 1104
1100 1100 600 1058
Table 14 Current ratings—output
UPS Rating
Voltage, VAC
Nominal
CurrentkVA kW
625 625 480 752
625 625 575 628
625 625 600 601
1100 1100 480 1323
1100 1100 575 1104
1100 1100 600 1058
Table 15 Current ratings—battery
UPS Rating
Nominal
VDC
Maximum
Battery
CurrentkVA kW
625 625 480 1636
625 625 480 1636
625 625 480 1636
1100 1100 480 2883
1100 1100 480 2883
1100 1100 480 2883
