Emerson Liebert NXL User Manual

Installation Drawings
32
Figure 22 Output terminal detail, 625kVA Liebert NXL, N+1 multi-module unit without static bypass
(continued)
NOTES:
1. All dimensions are in inches (mm)
2. Control wiring and power wiring must be run in separate conduits.
3. Aluminum and copper-clad aluminum cables are not recommended.
4. All wiring is to be in accordance with national and local electrical
codes.
Neutral
Output
Ground
Output
Phases
RIGHT SIDE (OUTPUT)
RIGHT FRONT
A
B
C
OUTPUT GROUND
O
1.57 (40) Typ.
1.38 X .56 Slot
10 Places
NEUTRAL
O
1.38 x .5
Slot 5
Places Each
Busbar
OUTPUT
PHASES
O
1.75
(44) Typ.
(Top Entry)
1.75 (44)
Typ. (Bottom
Entry)
1.75 (44)
Typ. (Bottom
Entry)
1.75 (44)
Typ.
1.75 (44)
Typ. (Top
Entry)
.56 (14)
Typ. 5
Places
.56 (14)
Typ. 5
Places
.56 (14)
Typ. 20
Places
0
32.0
(813)
39.4
(1002)
53.2
(1352)
76.8
(1950)
DO NOT DOUBLE-STACK LUGS
CB1-3
CB1-3
