Installation Drawings
56
Table 10 Interconnects for 1100KVA UPS single module unit
Cable
Part #
Cabinet Start
Connector
Label
Cabinet Finish
Connector
Label
Notes
531983G3 DC - UPSC Board P0701 Inverter - Load V/I Board P0701 Route in Front Duct
531988G8 DC - UPSC Board P0700 Inverter - Load V/I Board P0700 Route in Front Duct
531985G10 DC - UPSC Board P0400A
Inverter - Parallel
Interface Board
P0400A Route in Front Duct
531985G11 DC - UPSC Board P0400B
Inverter - Parallel
Interface Board
P0400B Route in Front Duct
531985G12 DC - UPSC Board P0400C
Inverter - Parallel
Interface Board
P0400C Route in Front Duct
544895G1 DC - EIB Board P0814
Inverter - Parallel
Interface Board
P814 Route in Front Duct
531987G3 DC - UPSC Board P0600 Rectifier - Source V/I Board P0600 Route in Front Duct
531984G10 DC - UPSC Board P0601 Rectifier - Source V/I Board P0601 Route in Front Duct
531986G6 DC - UPSC Board P0300D
Rectifier - Delta Gate
Drive Board
P0300D Route in Front Duct
531986G7 DC - UPSC Board P0300Y
Rectifier - Wye Gate
Drive Board
P0300Y Route in Front Duct
544897G1
Rectifier - Source V/I
Board
P0606 DC - Batt Hall Sensor HP1 Route in Front Duct
Rectifier - Fuses F1, F6
F1NC2,
F6COM1
Inverter - Parallel
Interface Board
P0814R
545311G1
Rectifier - FIB1 P99 DC - EIB Board P66B Route in Front Duct
Rectifier - FIB1 P66
Inverter - Parallel
Interface Board
P99B
546357G1 Rectifier - Fuses F7, F9
F7COM1,
F9NC2
DC - EIB Board TB0840 Route in Front Duct
544891G1
Input - CB Interface
Board
P1100 Rectifier - Source V/I Board P1100S Route in Front Duct
Input - CT1 X1, X2 Rectifier - Source V/I Board P0607
Input - CT2 X1, X2 Rectifier - Source V/I Board P0608
Input - Fuses F50-F52
F50-2, F51-2,
F52-2
Rectifier - Source V/I Board P0603
Input - Fuses F46, F47 F46-2, F47-2
DC - P1304 (Connect to
Connector in Rear Duct
Labeled P1304J)
P1304J Route in rear duct
531984G9 DC - UPSC Board P0500 Bypass - BPSS Board P0500 Route in Front Duct
531988G7 DC - UPSC Board P0501 Bypass - BPSS Board P0501 Route in Front Duct
544900G1 Bypass - FIB4 P99
Inverter - Parallel
Interface Board
P66B Route in Front Duct
545848G1
DC - Power Supply P99 Bypass - FIB4 P66 Route in Front Duct
DC - Power Supply P44 Bypass - BPSS Board P44
544902G1
Bypass - CT7 X1, X2 Inverter - Load V/I Board P0713
Route through bushing
in right side of inverter
cabinet
Bypass - CT8 X1, X2 Inverter - Load V/I Board P0714
Bypass - CT9 X1, X2 Inverter - Load V/I Board P0715
Bypass - CB2
Interface Board
P1103 Inverter - Fuses F36, F37 F36-2, F37-2
Bypass - Fuses F89-F92
F89-2, F90-2,
F91-2, F92-2
Inverter - Load V/I Board P0702
544904G1
Bypass - PS Service PS SERVICE
DC - P1305 (Connect to
Connector in Rear Duct
Labeled P1305J)
P1305J Route in Rear Duct
Bypass - Fuses F42, F43
F42-2,
F43-2
DC - P1306 (Connect to
Connector in Rear Duct
Labeled P1306J)
P1306J
