Installation Drawings
51
Table 9 Interconnects for 1100kVA UPS multi-module unit
Cable
Part #. Cabinet Start
Connector
Label Cabinet Finish
Connector
Label Notes
531983G3 DC - UPSC Board P0701 Inverter - Load V/I Board P0701 Route in Front Duct
531988G8 DC - UPSC Board P0700 Inverter - Load V/I Board P0700 Route in Front Duct
531985G10 DC - UPSC Board P0400A
Inverter - Parallel
Interface Board
P0400A Route in Front Duct
531985G11 DC - UPSC Board P0400B
Inverter - Parallel
Interface Board
P0400B Route in Front Duct
531985G12 DC - UPSC Board P0400C
Inverter - Parallel
Interface Board
P0400C Route in Front Duct
544895G1 DC - EIB Board P0814
Inverter - Parallel
Interface Board
P814 Route in Front Duct
531987G3 DC - UPSC Board P0600
Rectifier - Source V/I
Board
P0600 Route in Front Duct
531984G10 DC - UPSC Board P0601
Rectifier - Source V/I
Board
P0601 Route in Front Duct
531986G6 DC - UPSC Board P0300D
Rectifier - Delta Gate
Drive Board
P0300D Route in Front Duct
531986G7 DC - UPSC Board P0300Y
Rectifier - Wye Gate
Drive Board
P0300Y Route in Front Duct
546920G1 DC-PS Board P99B
Inverter Parallel
Interface - Board
P66B Route in Front Duct
544897G1
Rectifier - Source
V/I Board
P0606 DC - Batt Hall Sensor HP1 Route in Front Duct
Rectifier - Fuses
F1, F6
F1NC2, F6COM1
Inverter - Parallel
Interface Board
P0814R
545311G1
Rectifier - FIB1 P99 DC - EIB Board P66B Route in Front Duct
Rectifier - FIB1 P66
Inverter - Parallel
Interface Board
P99B
546357G1 Rectifier - Fuses F7, F9 F7COM1, F9NC2 Dc -EIB Board TB0840 Route in Front Duct
544891G1
Input - CB
Interface Board
P1100
Rectifier - Source V/I
Board
P1100S Route in Front Duct
Input - CT1 X1, X2
Rectifier - Source V/I
Board
P0607
Input - CT2 X1, X2
Rectifier - Source V/I
Board
P0608
Input - Fuses
F50-F52
F50-2, F51-2, F52-2
Rectifier - Source V/I
Board
P0603
Not Required for
Remote CB1 (RIB)
Input - Fuses
F46, F47
F46-2, F47-2
DC - P1304 (Connect to
Connector In Rear Duct
Labeled P1304J)
P1304J Route in Rear Duct
To Next Page
