Installation Drawings
35
WH P/N
START
(Part A - Rectifier Cabinet)
FINISH
(Part B - Inverter Cabinet) LABEL
531985G1 UPSC (Control Door) 02-806704 - Inverter Gate Drive A
To: 02-806704- Phase A
ID: P0400A
531988G2 UPSC (Control Door) 02-806707 - Load VI
To: 02-806707-
ID: P0700
531983G1 UPSC (Control Door) 02-806707- Load VI
To: 02-806707-
ID: P0701
531985G2 UPSC (Control Door) 02-806704 - Inverter Gate Drive B
To: 02-806704- Phase B
ID: P0400B
531985G3 UPSC (Control Door) 02-806704 - Inverter Gate Drive C
To: 02-806704-
Phase C
ID: P0400C
532061G1 Power Supply 02-806716 - AC Distribution Board
To: 02-806716-__
Connection ID: P1305
WH P/N: 532061G1
To Next Page
