Emerson Liebert NXL User Manual

Installation Drawings
37
WH P/N
START
(Part B - Inverter Cabinet)
FINISH
(Part A - Rectifier Cabinet) LABEL
532049G1 02-806716- AC Distribution Board 02-806710- Fan Interface Board 1
To: 02-806710-__
Connection ID: P1011
WH P/N: 532049G1
532065G1 02-806710- Fan Interface Board 2 02-806710- Fan Interface Board 1
To: 02-806710-__
Connection ID: P66
WH P/N: 532065G1
532063G1 DC Fuse 02-806708- External Interface Board
To: 02-806708-__
Connection ID: P0814
WH P/N: 532063G1
532065G1 02-806710- Fan Interface Board 3 02-806708- External Interface Board
TO: 02-806708-__
Connection ID: P99B
WH P/N: 532065G1
