Emerson PACSystems Versamax - Genius NIU Specifications; Genius NIU Compatibility

PACSystems VersaMax Genius Network Interface User Manual Section 1
GFK-1535D Jan 2023
Introduction 6
1.6 Genius NIU Specifications
Feature
Specification
Number of Modules
8 per rack, 64 per NIU/station
Network inputs per bus scan
128 bytes
Network outputs per bus scan
128 bytes
Discrete Input Memory
1024 points
Discrete Output Memory
1024 points
Analog Input Memory
128 bytes
Analog Output Memory
128 bytes
Power Consumption
+5V@250mA, +3.3V@10mA
Serial Bus Address
0 to 31
Network data rate
153.6 Kbaud extended, 153.6 Kbaud standard,
76.8 Kbaud, or 38.4 Kbaud.
1.6.1 Genius NIU Compatibility
Network Interface Unit IC200GBI001 is compatible with any type of PLC
or computer capable of controlling the Genius bus. Examples:
• PACSystems RX7i controller
• PACSystems RX3i controller
• Series 90™-70 PLC
• Series 90™-30 PLC
For some products, minimum versions are required for use with a Genius
NIU:
• On a Genius bus controlled by an IC697 PLC or PACSystems RX7i:
—
IC697 CPU firmware, release 3.0 or later.
—
Genius Bus Controller release 5.4 or later. Upgrading the 90-
70
—
Genius Bus Controller firmware to version 6.0 (or higher) is
strongly recommended.
• For a Series 90™-30 PLC
—
CPU firmware: any version.
—
Bus Controller: any version.
