Emerson PACSystems Versamax - Installation

PACSystems VersaMax Genius Network Interface User Manual Section 2
GFK-1535D Jan 2023
Installation 17
Section 2: Installation
This section gives instructions for installing the Network Interface Unit
and the Genius® bus.
• Module clearance
• Thermal considerations
• Mounting instructions
• Panel-mounting
• Installing an Expansion Transmitter Module
• Installing an Expansion Receiver Module
• Installing Power Supply Modules
• Installing Additional Modules
• Setting the SBA and baud rate
• Special switch settings on the NIU
• Selecting a cable type
• Making bus connections
• Observing the LEDs
• CE Mark installation requirements
Additional installation instructions are located in the VersaMax Modules,
Power Supplies, and Carriers Manual, GFK-1504.
WARNING
•
Explosion hazard - substitution of components may impair suitability for Class I,
Division 2;
•
Explosion hazard - when in hazardous locations, turn off the power before replacing
or wiring modules; and
•
Explosion hazard - do not connect or disconnect equipment unless power has been
switched off or the area is known to be non-hazardous.
