Emerson PACSystems Versamax - Configuration Data Formats

PACSystems VersaMax Genius Network Interface User Manual Section 5
GFK-1535D Jan 2023
Configuration 90
Write Configuration Data Format
Byte #
Description
0
Rack Number (0,…, 7)
1
Length of this message (must match the length for the specific device
whose configuration will be written.)
2
Slot (0,…, 9. Network Interface Unit is 1)
3
Packet number (0, 1, 2, …)
4, 5
Slot length (bytes)
6 – 31
“Rack/slot” record for the slot
32 to end
Context-dependent data (optional)
5.5.4 Configuration Data Formats
Power Supply and Carriers Configuration Data Format (Rack 0-7, slot 0)
(Byte in
Message)
(Byte in
Record)
Byte Description
6, 7
0, 1
not used (00,00)
8
2
major type (01)
9
3
power supply type: 0 = none
5 = IC200PWR001
10 = IC200PWR002
15 = IC200PWR101
20 = IC200PWR1021
40 = IC200PWB001 (carrier)
10,…, 13
4,…, 7
ASCII string Set to zeros during auto-configuration, the
programmer may fill this field with an arbitrary identification string.
14
8
2
15
9
Additive checksum for entire station configuration
16, 17
10, 11
CRC checksum for the entire station configuration
18
12
number of racks present (1)
19
13
number of slots (maximum 10)
20, 21
14, 15
Feature list (00 00). A bitmapped word is reserved for forward
compatibility with future releases. In the initial product release, this
value is zero.
22,…, 29
16,…, 23
not used
30, 31
24, 25
Length of additional data (52)
32, 33
0, 1
not used (00,00)
34
2
61h (97)
35
3
9
36,…, 39
4,…, 7
reserved (must be 00, 00, 00, 00)
