Emerson PACSystems Versamax - Page 97

PACSystems VersaMax Genius Network Interface User Manual Section 5
GFK-1535D Jan 2023
Configuration 91
(Byte in
Message)
(Byte in
Record)
Byte Description
40
8
first I/O module slot carrier type: 0 = none
5 = IC200CHS001
10 = IC200CHS002
15 = IC200CHS005
20 = IC200CHS010
25 = IC200CHS011
30 = IC200CHS015
35 = IC200CHS003
41
9
second I/O module slot carrier type
42
10
third I/O module slot carrier type
43
11
fourth I/O module slot carrier type
44
12
fifth I/O module slot carrier type
45
13
sixth I/O module slot carrier type
46
14
seventh I/O module slot carrier type
47
15
eighth I/O module slot carrier type
48,…, 55
16,.., 23
not used
56, 57
24, 25
Length of additional data (00, 00)
58, 59
0, 1
Must be 00, 00
60
2
61h (97)
61
3
0Ah (10)
62,…, 65
4,…, 7
Reserved (must be 00, 00)
66
8
first booster PS Carrier type:
0 = none
5 = IC200PWR001
10 = IC200PWR002
15 = IC200PWR101
20 = IC200PWR102
40 = IC200PWB001 (carrier)
67
9
first booster PS, Power Supply type (see above)
68
10
second booster PS Carrier type
69
11
second booster PS, Power Supply type
70
12
third booster PS Carrier type
71
13
third booster PS, Power Supply type
72
14
fourth booster PS Carrier type
73
15
fourth booster PS, Power Supply type
74
16
fifth booster PS Carrier type
75
17
fifth booster PS, Power Supply type (see above)
76
18
sixth booster PS Carrier type
77
19
sixth booster PS, Power Supply type
78
20
seventh booster PS Carrier type
79
21
seventh booster PS, Power Supply type
80,…, 81
22,…., 23
Reserved (must be 00, 00)
