PACSystems VersaMax Genius Network Interface User Manual Section 1
GFK-1535D Jan 2023
Introduction 7
1.7 Power Supplies
An AC or DC Power Supply module installs directly on the NIU. The Power
Supply provides +5 V and +3.3 V power to the modules in the station.
Additional power supplies can be installed on special booster carriers if
needed for systems where the number of modules creates the need for a
booster. No booster supply is needed to power conventional I/O
modules.
Figure 4: VersaMax Power Supply
Available Power Supplies and Carriers
The following VersaMax power supplies and carriers are available:
Power supplies are described in the VersaMax Modules, Power Supplies,
and Carriers User’s Manual (GFK-1504).
