PACSystems VersaMax Genius Network Interface User Manual Section 1
GFK-1535D Jan 2023
Introduction 12
Available I/O Carriers and Terminal Strips
The following types of I/O Carriers, terminals, and cables are available:
Terminal-Style I/O Carriers
Part Description
Part Number
Barrier-Style Terminal I/O Carrier
IC200CHS001
Box-Style Terminal I/O Carrier
IC200CHS002
Spring-Style Terminal I/O Carrier
IC200CHS005
Compact Terminal-Style I/O Carriers
Compact Box-Style I/O Carrier
IC200CHS022
Compact Spring-Style I/O Carrier
IC200CHS025
Connector-Style I/O Carrier
Connector-Style I/O Carrier
IC200CHS003
Interposing Terminals for use with Connector-Style Carrier
Barrier-Style Interposing I/O Terminals
IC200CHS011
Box-Style Interposing I/O Terminals
IC200CHS012
Thermocouple-Style Interposing I/O Terminals
IC200CHS014
Spring-Style Interposing I/O Terminals
IC200CHS015
Disconnect-Style Interposing I/O Terminals, Main Base
Disconnect-Style Interposing I/O Terminals, Expansion Base
IC200CHS101
IC200CHS102
Relay-Style Interposing I/O Terminals, Main Base
Relay-Style Interposing I/O Terminals, Expansion Base
IC200CHS111
IC200CHS112
Fuse-Style Interposing I/O Terminals, Main Base
Fuse-Style Interposing I/O Terminals, Expansion Base
IC200CHS121
IC200CHS122
Cables for use with Connector-Style I/O Carriers
2 connectors, 0.5m, no shield
IC200CBL105
2 connectors, 1.0m, no shield
IC200CBL110
2 connectors, 2.0m, no shield
IC200CBL120
1 connector, 3.0m, no shield
IC200CBL230
Auxiliary I/O Terminal Strips for use with Terminal-style I/O Carriers and
Interposing Terminals
Barrier-Style Auxiliary I/O Terminal Strip
IC200TBM001
Box-Style Auxiliary I/O Terminal Strip
IC200TBM002
Spring-Style Auxiliary I/O Terminal Strip
IC200TBM005
Other Carriers
Communications Carrier
IC200CHS006
Power Supply Booster Carrier
IC200PWB001
