PACSystems VersaMax Genius Network Interface User Manual Section 3
GFK-1535D Jan 2023
Operation 59
Number of Analog Modules IC200ALG265 and IC200ALG266
Configured in the Station
1
2
3
4
Number of
additional
I/O Bytes
Transferred
on the
Genius Bus
Genius
Bus
Scan Time
Max GNIU
Sweep
Time
Genius
Bus
Scan
Time
Max GNIU
Sweep
Time
Genius
Bus
Scan Time
Max GNIU
Sweep
Time
Genius
Bus
Scan Time
Max GNIU
Sweep
Time
80
47
10.4
58
11.2
68
12.6
76
13.2
88
51
10.4
60
11.2
70
12.6
78
13.1
96
53
10.4
63
11.2
72
12.6
80
13.2
104
55
10.4
65
11.2
74
12.6
83
13.2
112
58
10.4
68
11.2
76
12.6
86
13.2
120
61
10.4
70
11.2
78
12.6
88
13.2
128
63
10.4
72
11.2
80
12.6
90
13.2
…
256
102
10.4
112
11.2
121
12.4
130
13.2
