Reference Manual
00809-0100-4731, Rev FA
April 2003
APEX
™
and APEX Sentry
™
Radar Gauge
A-6
Temperature and Pressure Operating Range
Nozzle Temperature Maximum Pressure Pressure vs. Temperature
–40°F to 104°F
(–40°C to 40°C)
Full vacuum to 155 psig
(full vacuum to 10,69 bar)
302°F
(150°C)
Full vacuum to 110 psig
(full vacuum to 7,59 bar)
374°F
(190°C)
Full vacuum to 10 psig
(full vacuum to 0,69 bar)
155
155
-15
110
150
175
75
50
100
125
300 400350200 25015050 100
25
Temperature (°F)
Pressure (psig)
-25
-50
10
-15
OPERATING RANGE
3750_03A
PTFE Window Temperature and Pressure Operating Range
Nozzle Temperature Maximum Pressure Pressure vs. Temperature
–4°F
(–20°C)
Full vacuum to 120 psig
(full vacuum to 8,2 bar)
104°F
(40°C)
Full vacuum to 90 psig
(full vacuum to 6,2 bar)
212 to 302°F
(100 to 150°C)
Full vacuum to 10 psig
(full vacuum to 0,69 bar)
Temperature (°F)
Pressure (psig)
OPERATING RANGE
5
155 205180
105
13080
30
55 255
305
280
230
–20
75
50
100
125
25
-25
120
90
10 10
-15
-15
3750_02A
