Reference Manual

00809-0100-4731, Rev FA

April 2003

APEX

™

and APEX Sentry

™

Radar Gauge

A-12

ORDERING

INFORMATION

Model Product Description Availability

APEX Radar Level Gauge for Tough Process Conditions ●

SENTRY Radar Level Gauge for Less Severe Process Conditions ●

Code Software

B Standard ●

Code Frequency Sweep

C 24 – 26 GHz ●

Code Outputs

1 4–20 mA with digital signal based on HART

protocol ●

2 Intrinsically Safe 4–20 mA with digital signal based on HART protocol

(Intrinsically safe output available only with hazardous location approval, Option Codes E5, E6, or ED

For hazardous locations drawings and examples of labels, see Appendix C in the reference manual (document

number 00809-0100-4731). Also, the RTD connection is not available with IS Output. Must be used with

Galvanically Isolated Barriers.

●

Code Power Supply

A 90 – 250 V ac ●

D 18 – 36 V dc ●

Code Conduit Threads

1 ¾–14 NPT ●

2 CM20 conduit adapter ●

3 PG 13.5 conduit adapter ●

Code Materials of Construction: Flange/Antenna

S 316L stainless steel ●

Code Antenna Type

C Cone ●

Code Antenna Size

2N Fits 2-inch opening ●

3N Fits 3-inch opening ●

4N Fits 4-inch opening ●

Code Mounting Flange Size

02 2-inch ASME B 16.5 (ANSI) (DN 50)

(Not available with mounting flange rating option code D2)

●

03 3-inch ASME B 16.5 (ANSI) (DN 80) ●

04 4-inch ASME B 16.5 (ANSI) (DN 100) ●

06 6-inch ASME B 16.5 (ANSI) (DN 150) ●

Code Mounting Flange Rating

A1 ASME B 16.5 (ANSI) class 150 ●

A3 ASME B 16.5 (ANSI) class 300 ●

D2 DIN PN 16 ●

D4 DIN PN 40 ●
