Cerabar S/Deltabar S Description of parameters (ToF Tool)
Endress+Hauser 109
FULL CALIB.
Entry
Enter level value for the upper calibration point (container full).
The container is either completely or almost full. By entering a value for this parameter,
you are assigning a level value to the pressure present at the device. → See also FULL
PRESSURE.
Prerequisite:
• CALIBRATION MODE = wet
Factory setting:
100.0
FULL PRESSURE
Display
Displays the pressure value for the upper calibration point (container full).
→ See also FULL CALIB.
Prerequisite:
• CALIBRATION MODE = wet
Factory setting:
High sensor limit (→ see PRESS. SENS HILIM, Page 140)
ADJUSTED DENSITY
Display
Displays the density calculated from the upper and lower level point.
Prerequisite:
• CALIBRATION MODE = wet, LIN. MEASURAND = level
DENSITY UNIT
Selection
Select density unit.
Prerequisite:
• LIN. MEASURAND = level, CALIBRATION MODE = dry
• LIN. MEASURAND = % (level), CALIBRATION MODE = dry
• LIN. MEASURAND = volume, CALIBRATION MODE = dry
• LIN. MEASURAND = mass, CALIBRATION MODE = dry
Options:
• g/cm
3
•kg/dm
3
•kg/m
3
• US lb/in
3
• US lb/ft
3
Factory setting:
kg/dm
3
ADJUST DENSITY
Entry
Enter density of fluid.
Prerequisite:
• LIN. MEASURAND = level, CALIBRATION MODE = dry
• LIN. MEASURAND = % (level), CALIBRATION MODE = dry
• LIN. MEASURAND = volume, CALIBRATION MODE = dry
• LIN. MEASURAND = mass, CALIBRATION MODE = dry
Factory setting:
1000.0
TANK VOLUME
Entry
Enter tank volume.
Prerequisite:
• LIN. MEASURAND = volume, CALIBRATION MODE = dry
• LIN. MEASURAND = mass, CALIBRATION MODE = dry
Factory setting:
1.0 m
3
TANK HEIGHT
Entry
Enter tank height.
Prerequisite:
• LIN. MEASURAND = volume, CALIBRATION MODE = dry
• LIN. MEASURAND = mass, CALIBRATION MODE = dry
Factory setting:
1.0 m
ToF Tool, Table 7: OPERATING MENU → SETTINGS → BASIC SETUP "Level", LEVEL MODE "Linear"
Parameter name Description
