Description of parameters (ToF Tool) Cerabar S/Deltabar S
120 Endress+Hauser
CUSTOMER UNIT M
Entry
Enter text (unit) for customer-specific mass unit.
You can enter a maximum of eight alphanumeric characters here. → See also CUST.
UNIT FACT. M.
Prerequisite:
• COMB. MEASURAND = height and mass, MASS UNIT = user unit
• COMB. MEASURAND = %-height and mass, MASS UNIT = user unit
!
Note!
Only the first five characters are shown on the on-site display. For example, if "crates" is
specified as the customer-specific unit, "crate" is displayed.
If the unit contains a slash, up to eight characters can be shown on the on-site display.
The maximum number of characters in the counter is again limited to five. For example,
if "crates/m2" is specified as the customer-specific unit, "crate/m2" is displayed. In the
ToF Tool, all eight characters are displayed.
Factory setting:
_ _ _ _ _ _ _ _
CUST. UNIT FACT. M
Entry
Enter conversion factor for a customer-specific mass unit.
The conversion factor must be entered in relation to the SI unit "kg". → See also
CUSTOMER UNIT M.
Prerequisite:
• COMB. MEASURAND = height and mass, MASS UNIT = user unit
• COMB. MEASURAND = %-height and mass, MASS UNIT = user unit
Example:
– You want the measured value to be displayed in "buckets".
– MEASURED VALUE = 10 kg i 1 bucket
– Entry CUSTOMER UNIT M: bucket
– Entry CUST. UNIT FACT. M: 0.1
– Result: MEASURED VALUE = 1 bucket
Factory setting:
1.0
LEVEL MIN
Entry
Enter the minimum level to be expected.
The input limits for the calibration (editing limits) are derived from the value entered. The
closer the value entered corresponds to the minimum level to be expected, the more
accurate the measurement result.
Factory setting:
0.0
LEVEL MAX
Entry
Enter the maximum level to be expected.
The input limits for the calibration (editing limits) are derived from the value entered. The
closer the value entered corresponds to the maximum level to be expected, the more
accurate the measurement result.
Factory setting:
100.0
ToF Tool, Table 9: OPERATING MENU → SETTINGS → BASIC SETUP "Level",
LEVEL MODE "Height linearized"
Parameter name Description
