Cerabar S/Deltabar S Description of parameters (FF configuration program)
Endress+Hauser 43
VOLUME_UNIT_TEXT/
CUSTOMER UNIT V
Entry
Index: 54
Data type: Visible String
Access: Auto, OOS
Enter text (unit) for customer-specific volume unit.
You can enter a maximum of eight alphanumeric characters here. → See also
VOLUME_UNIT_SCALE/CUST. UNIT FACT. V.
Prerequisite:
• MEASURAND_COMBINED = height and volume, VOLUME_UNIT = user unit
• MEASURAND_COMBINED = %-height and volume, VOLUME_UNIT = user unit
– MEASURAND_COMBINED = COMB. MEASURAND
– VOLUME_UNIT= UNIT VOLUME
!
Note!
Only the first five characters are shown on the on-site display. For example, if "crates" is
specified as the customer-specific unit, "crate" is displayed.
If the unit contains a slash, up to eight characters can be shown on the on-site display. The
maximum number of characters in the counter is again limited to five. For example, if
"crates/m2" is specified as the customer-specific unit, "crate/m2" is displayed. In the FF
configuration program, the slash counts as a character, i.e. "crates/m2" would be displayed as
"crates/m".
Factory setting:
_ _ _ _ _ _ _ _
VOLUME_UNIT_SCALE
/CUST. UNIT FACT. V.
Entry
Index: 55
Data type: Float
Access: Auto, OOS
Enter conversion factor for a customer-specific volume unit.
The conversion factor must be entered in relation to the SI unit "m
3
".
→ See also VOLUME_UNIT_TEXT/CUSTOMER UNIT V.
Prerequisite:
• MEASURAND_COMBINED = height and volume, HEIGHT_UNIT = user unit
• MEASURAND_COMBINED = %-height and volume, HEIGHT_UNIT = user unit
– MEASURAND_COMBINED = COMB. MEASURAND
– VOLUME_UNIT= UNIT VOLUME
Example:
– You want the measured value to be displayed in "buckets".
– PRIMARY_VALUE = 0.01 m3 i 1 bucket
– Entry VOLUME_UNIT_TEXT/CUSTOMER UNIT V: bucket
– Entry VOLUME_UNIT_SCALE/CUST. UNIT FACT. V: 100
– Result: PRIMARY_VALUE = 1 bucket
Factory setting:
1.0
MASS_UNIT
Selection
Index: 56
Data type: Unsigned16
Access: Auto, OOS
Select mass unit.
Prerequisite:
• MEASURAND_LINEARIZED/LINd. MEASURAND = pressure and mass
Options:
•g
•kg
•t
•oz
•lb
•ton
•User unit, → See also the following parameter descriptions for MASS_UNIT_TEXT/
CUSTOMER UNIT M (Page 44) and MASS_UNIT_SCALE/CUST. UNIT FACT. M
(Page 44)
Factory setting:
kg
Pressure Transducer Block
Parameter Description
