Endress+Hauser Mycom CLM 152 Operating Instructions

4.4.1 Connecting the Mycom CLM 152 in non-hazardous area
FCL1 module (Slot 1, basic configuration):
11 Pt 100 terminal, sensor line
12 Pt 100 terminal, sensor line
13 Cable compensation terminal
Inductive sensor
14 Transmitter coil inner conductor
15 Transmitter coil screen
16 Receiver coil screen
17 Receiver coil inner conductor
Conductive sensor
14 Electrode cable screen
15 not connected
16 not connected
17 Electrode cable inner conductor
Terminal blocks (basic configuration):
Power supply:
L/L+ AC voltage, phase or DC +
N/L– AC voltage, neutral or DC –
PE Protective earth
Active current output:
31 Current output (Cd signal) positive
32 Current output (Cd signal) negative
33 Current output (temp. signal) positive
34 Current output (Temp. signal) negative
Output contacts:
85 Alarm contact
86 Alarm contact
87 Contact 1
88 Contact 1
88 87 85 86
Power
supply
31 32 33 34
II
12
K1
Analog out
0/4...20mA
max. 600
Relay
contact
250 Vac / 2A
( cos =1)
125 Vdc / 3A
PEmA mA
SLOT 1
SLOT 2
SLOT 3
SLOT 4
FCL1
F101
M 3,15A / 250V
LLN
L+ L+ L –
LM152AR.CDR
Fig. 4.6
Wiring compartment of
Mycom CLM 152 non-Ex
(base version)
11 12 13 14 15 16 17 31 32 33 34 85 86 87 88 AC: L L N PE
bl rd rd bl
ϑ
Con
Con
mA mA
ϑ
Contact 1Fail
Pt 100
+ − + −
LM152CON.CDR
send (wt)
Aux. voltage
Basic moduleConductivity input module FCL 1
(Slot 1)
DC: L+ L+ L–
Temperature Conductivity Conductivity Temperature
receive (rd)
14 15 16 17
Only
two-electrode
sensors
connectable
n.c. n.c.
Fig. 4.7
Wiring diagram of Mycom
CLM 152 (base version)
inductive
conductive
lm152e04.chp
Mycom CLM 152 Installation
Endress+Hauser 13
