Wiring compartment and wiring diagram
PARAM
MEAS CAL
DIAG PARAM
MEAS CAL
DIAG
non-hazardous area
Measuring current
circuit ia
Supply
circuit
lm152_ex.cdr
Signal output
circuit ia
Ex zone 1
Fig. 4.13
Inductive sensor and
measuring transmitter in
Ex zone
88 87 85 86
K1
2x Optocoupler
max. 30 Vdc / 100mA / 750mW
+ +
PE
SLOT 1
SLOT 2
SLOT 3
SLOT 4
FCL1
Analog
out
Power-
supply
Sicherung / fuse:
50076930
100V..230V
50076931 24Vac
50087807 24Vdc
L
L+
N
L-
F
F
lm152arx.cdr
Fig. 4.14
Wiring compartment of
Mycom CLM 152-Z (Ex)
lm152e04.chp
Mycom CLM 152 Installation
Endress+Hauser 17
