Start-up / Checklist
continued
Request
see
Chapter
Selection options Factory setttings User settings
Input contact
(only with FCXI card)
7.1.1
2xHold;
1xHold + 1xremote switch-over; 2xremote
switch-over
2xHold
Relay function 7.1.4
2 relays
Maintenance, limit (for base version)
Maintenance
5 relays (only with FCYK)
NAMUR
1)
/ limit
Clean / 2xlimit
Clean / 1xlimit / 1xservice
NAMUR
1)
/ MRS
2)
NAMUR
1)
/ 1xlimit / USP
3)
Wartung / limit / MRS
2)
NAMUR1) / limit
NAMUR contacts
1)
7.1.4
NC contact,
NO contact
NO contact
Failure relay 7.1.4
Fleeting contact,
Steady contact
Steady contact
Fault contact 7.1.4
Assignement of fault:
to maintenance contact,
to no contact
Maintenance contact
Start-up
End,
Resume
end
1)
As per recommendation of NAMUR (Standardisation Committee for Measurement and Control in the German Chemical Industry)
2)
MRS = measuring range switch-over
3)
USP = pure water measurement acc. »United States Pharmacopeia«
