Endress+Hauser Mycom CLM 152 Operating Instructions

7.1.3 Code
7.1.4 Output contacts
Caution:
• Before power-up, check that
the wiring corresponds to the
contact configuration you
selected.
• The contacts of the non-Ex version
have a different behaviour in case
of power failure (see Table
Contact assignment on the
next page).
Function Selection Factory setting
Enter required maintenance code
(0000 = no lock)
0000 ... 9999 0000
Enter required specialist code
(0000 = no lock)
0000 ... 9999 0000
Function Selection Factory setting
Base version (2 output contacts)
Function for contact 1
1)
Maintenance’
Limit
USP (for conductivity conductive only)
Maintenance
NAMUR
2)
contact type NC contact, NO contact NO contact
Failure relay contact type
Steady contact
Fleeting contact
Steady contact
Assign E055-E078
to maintenance contact
to maintenance contact
to no contact
to maintenance
contact
If equipped with FCYK expansion module (5 output contacts)
Function for contacts 1 ... 4
1)
Inductive
NAMUR
2)
/ limit
NAMUR
2)
/ MR switch-over
3)
Maintenance / limit / MRS
3)
1 x limit / Chemoclean
2 x limit / Chemoclean
konductive
NAMUR / limit / USP
NAMUR / limit
1)
see Table „Contact assignment“ on next page
2)
As per recommendation of NAMUR (Standardisation Committee for Measurement and Control in the German
Chemical Industry)
3)
Relay configuration with MR switch-over in conductivity/single-circuit-mode only
Instrument configuration Mycom CLM 152
38 Endress+Hauser
