Hinweis:
The »fault contact« is active in case
of system faults and defects
(error codes 1 to 23) which can
cause the instrument to fail.
The preset error current is output at
current outputs 1 and 2
(see Chapter 7.2.1).
The fault contact is defaulted for all
settings.
The »maintenance contact«, if
configured, signals faults in the
instrument or process.
Operation can continue but the
measuring system will then require
an inspection.
Depending on the configuration in
7.1.4 the maintenance contact is
signalled in fault codes
30 to 52 or 30 to 78.
The »function check« contact is
active in Hold state and when
settings are made to the instrument
(e.g. during calibration and
configuration).
Contact assignment in base version
Select »Maintenance« Select »Limit« Select »USP«
Failure contact
Tl. 85/86
Failure
1)
Failure
1)
Failure
1)
Contact 1
Tl. 87/88
Maintenance required
2)
Limit contact
2)
USP
2)
Relay contact of non-Ex version on power failure:
1)
active (NO contact closed, NC contact open)
2)
passive (NO contact open, NC contact closed)
Contact assignment when FYCK expansion module equipped
Select
»NAMUR«,
Limit
»NAMUR«
/
MR switch-
over
Maintenance
/ limit / MRS
1 x limit
Chemoclean
2 x limit
Chemoclean
NAMUR /
limit / USP
Failure contact
Tl. 85/86
Failure
1)
Failure
1)
Failure
1)
Failure
1)
Failure
1)
Failure
1)
Contact 1
Tl. 87/88
Maintenance
required
2)
Maintenance
required
2)
Maintenance
required
2)
Maintenance
required
2)
Limit
contact 1
2)
Maintenance
required
2)
Contact 2
Tl. 89/90
Function
check
2)
Function
check
2)
Limit
contact
2)
Limit
contact
2)
Limit
contact 2
2)
Function
check
2)
Contact 3
Tl. 91/92
Limit
contact 1
2)
MRS 1
2)
MRS 1
2)
Water
3)
Water
3)
Limit
contact
2)
Contact 4
Tl. 93/94
Limit
contact 2
2)
MRS 2 2) MRS 2
2)
Clean.
agent
3)
Clean.
agent
3)
USP
2)
Relay contact of non-Ex version on power failure:
1)
active (NO contact closed, NC contact open)
2)
passive (NO contact open, NC contact closed)
