Example of a current output table for log 3
Programming the current output table:
Current output [%]
Conductivity [µS/cm]
Current output [%]
Conductivity [µS/cm]
0 0.1 55 4.47
5 0.14 60 6.31
10 0.2 65 8.91
15 0.28 70 12.6
20 0.4 75 17.8
25 0.56 80 25.1
30 0.79 85 35.5
35 1.12 90 50.1
40 1.58 95 70.8
45 2.24 100 100
50 3.16
Function Selection Factory setting
Select support point
Enter number of support point
2...21
2
Enter value for current output
(%) and conductivity
0 ... 100 %
0 ... Measuring value final
value (dependent on
connected sensor, see p. 43)
Status display
Current output and
conductivity value must
increase from element to
element, otherwise an error
message will appear:
• „Percentage values
monotone non-increasing»
or
• „CD values monotone
non-increasing
Instrument configuration Mycom CLM 152
46 Endress+Hauser
