Enerpac JS125 - Page 81

www.enerpac.com
Document number: ED.03783.00.001.ENG rev 4 Page 81 of 153
6.4.1.5 Automatic control
Without automatic insert table With automatic insert table
Lifting
Start the lifting sequence.
Once pressed, the text changes to “Hold lifting” which enables you to
temporize the movement.
Stop
To stop all movements.
Lowering
Start the lowering sequence.
Once pressed, the text changes to “Hold lowering” which enables
you to temporize the movement.
Remove Barrel from Unit
(only with automatic insert
table)
The Barrel is automatically removed from the unit
Stop
(only with automatic insert
table)
To stop all movements
Place barrel in Unit (only
with automatic insert
table)
The Barrel is automatically placed in the unit
Unloaded operation
No real load is lifted.
The system will not perform a preload measurement.
Proceed
- When lifting a load, click after a new barrel was inserted
- When lowering a load, click after a barrel was removed
Back to menu
Return to main menu
