Section 2 — Algorithms
ENSONIQ DP/4+ Reference Manual 93
TUNABLE SPKR 1
Tunable Spkr 1 offers an EQ controllable speaker sound which is brighter than Speaker Cabinet.
By tuning three parametric filters, you can simulate many different speaker cabinet sounds that
are used in all styles of music.
01 — Mix
02 — Volume
See the descriptions under the Mix and Volume Parameters, in the beginning of this section.
03 — Mid1 Fc Range: 100 to 9999 Hz
Sets the center of the mid-frequency parametric. Higher values have a brighter sound.
04 — Mid1 Gain Range: -48 to +24 dB
Sets the amount of cut (negative values) or boost (positive values) applied to this mid-frequency
parametric.
05 — Mid1 Q Range: 01 to 18
This parameter is a bandwidth control that determines the width of the resonant peak at the
center of the frequency band. By raising the value, you can produce a narrower bandwidth.
06 — Mid2 Fc 09 — Mid3 Fc
07 — Mid2 Gain 10 — Mid3 Gain
08 — Mid2 Q 11 — Mid3 Q
These parameters are identical to the previous ones, but can be assigned to control different
bandwidths within the mid-range.
12 — Speaker Input Attenuation Range: -24 to +00 dB
This parameter allows you to adjust the input level before the EQs to eliminate the possibility of
clipping boosted signals.
13 — Speaker Output Gain Range: -48 to +24 dB
Since speaker cabinets are “lossy,” output gain is required to compensate losses in perceived
volume. Setting this gain too high will cause clipping of the output signal.
14 — Mod1 Source 18 — Mod2 Source
15 — Mod1 Destination 19 — Mod2 Destination
16 — Mod1 Param Range Min 20 — Mod2 Param Range Min
17 — Mod1 Param Range Max21 — Mod2 Param Range Max
See the descriptions under the Algorithm Modulators in the beginning of this section.
